| Motor | Motor Type Brushless Rotational Speed 1000 rpm (Maximum) Maximum Torque 0.25N x m Maximum Output Power 19 W Operating Temperature 14 to 104oF / -10 to 40oC Driver Field Oriented Control (FOC) Control Method Closed-Loop Speed Control Protections Overvoltage Overtemperature Soft-Start Short-Circuit Chip and Sensory Anomaly |
| Gimbal | Controllable Range -20o to +35o (Pitch) +/- 250o (Yaw) Mechanical Range -24o to +41o (Pitch) +/- 270o (Yaw) Rotational Speed 540o/s Vibration +/- 0.02o (On the platform surface with the blaster idle) |
| Controller | Latency Connection via Wi-Fi: 80-100 ms Connection via Router: 100-120 ms NOTE: Latency times depend on environmental conditions and mobile device Live View Resolution 720p/30 FPS Live View Resolution: 720p/30 FPS Max Live View Bitrate: 6 Mb/s Operating Frequencies 2.4 GHz, 5.1 GHz, and 5.8 GHz Operating Mode Connection via Wi-Fi Connection via Router Maximum Transmission Distance Connection via Wi-Fi FCC: 2.4 GHz 55.1" / 140.0 cm / 5.8 GHz 35.4" / 90.0 cm CE: 2.4 GHz 55.1" / 140.0 cm / 5.8 GHz 27.6" / 70.0 cm SRRC: 2.4 GHz 51.2" / 130.0 cm / 5.8 GHz 51.2" / 130.0 cm MIC: 2.4 GHz 66.9" / 170.0 cm / 5.1 GHz 55.1" / 140.0 cm Connection via Router FCC: 2.4 GHz 70.9" / 180.0 cm / 5.8 GHz 118.1" / 300.0 cm CE: 2.4 GHz 70.9" / 180.0 cm / 5.8 GHz 39.4" / 100.0 cm SRRC: 2.4 GHz 70.9" / 180.0 cm / 5.8 GHz 118.1" / 300.0 cm MIC: 2.4 GHz 66.9" / 170.0 cm / 5.1 GHz 70.9" / 180.0 cm Transmission Power (EIRP) 2.400-2.4835 GHz FCC: less-than or equal to 30 dBm SRRC: less-than or equal to 20 dBm MIC: less-than or equal to 20 dBm 5.170-5.25 GHz FCC: less-than or equal to 30 dBm SRRC: less-than or equal to 23 dBm MIC: less-than or equal to 23 dBm 5.725-5.850 GHz FCC: less-than or equal to 30 dBm SRRC: less-than or equal to 30 dBm Transmission Protocol IEEE 802.11 a/b/g/n |
| Camera | Sensor CMOS 1/4" 5MP Effective Pixels FOV 120o Still Image Resolution 2560 x 1440 (Maximum) Video Resolution FHD: 1920 x 1080 30p (Maximum) HD: 1280 x 720 30p (Maximum) Video Bitrate 16 Mb/s Photo Format JPEG Video Format MP4 Operating Temperature 14 to 104oF / -10 to 40oC |
| IR Interface | Effective Range Narrow Infrared Units (indoor lighting): 19.7 / 6.0 m Wide Infrared Units (indoor lighting): 9.8 / 3.0 m Area Between 40o to 10o (Narrow Infrared Units effective area decreases as distance from the target increases) Width 360o (indoor lighting) |
| Battery | Capacity 2400 mAh Charging Voltage Nominal: 10.8 V Maximum: 12.6 V Battery Type Lithium-ion polymer (LiPo) 3S Energy 25.92 Wh Battery Life In Use: Up to 35 Minutes (Measured at a constant speed of 2 m/s on a flat surface) On Standby: Up to 100 Minutes Charging Power Output 29 W Charging Temperature Range 41 to 104oF / 5 to 40oC Operating Temperature 14 to 104oF / -10 to 40oC |
| Charger | Input 100-240 V, 50-60 Hz, 1 A Output 12.6 V equal 0.8 A or 12.6 V equal 2.2 A Voltage 12.6 V Rated Voltage 28 W |
| Chassis | Speed Range Forward: 0 to 3.5 m/s Backward: 0 to 2.5 m/s Sideways: 0 to 2.8 m/s Rotation Speed 600o/s (Maximum) |
| Other Specifications | Supports microSD cards up to 64 GB Blaster Controllable Launching Frequency: 1-8 Seconds Blaster Maximum Launching Frequency: 10 seconds Blaster Initial Launching Speed: (approximately) 26 m/s Blaster Average Load: (approximately) 430 Hit Detector Detection Requirements: For detection to be activated, the gel bead must be greater-than or equal to0.2" / 0.6 cm in diameter, launching speed must be greater-than or equal to20 m/s, and the angle between the hit direction and hit detector plane must be no less than 45o Hit Detector Maximum Detection Frequency: 15 Hz Gel Bead Diameter: 0.2 x 0.3" / 0.6 x 0.7 cm Gel Bead Weight: 0.1 oz / 0.1-0.2 g App Compatibility: iOS 9.0 or Later and Android 5.0 or Later |
| Dimensions and Weight | Item Dimension (L inchxW inchxH inch) 17 x 13 x 12 Weight 20.00 lb |
